QSC GX3

qx3_390856376
17,500.00 THB ต่อหน่วย Manufacturer: QSCQSC

รายละเอียดทั้งหมด :


QSC GX3 เครื่องขยายเสียง Power Amplifiers 8 ohm 2 x 300 W

Professional Power Amplifiers




Your Speaker's Power Rating

Model
GX3 For 8 ohm speakers:
250 W - 350 W (program)*
GX5 For 8 ohm speakers:
400 W - 600 W (program)**
* For 4Ω speakers: 350 W - 500 W (program)
** For 4Ω speakers: 550 W - 900 W (program)


Which GX amplifier is best for my loudspeakers?

Choose your loudspeaker model from a list and the amplifier selector can tell you which amplifier is right for you.
Find the right GX model for your loudspeakers



GX Series amplifiers are ideal for professional entertainers who require maximum performance and portability on a limited budget. QSC designers, headed by Pat Quilter, have optimized output and appearance while reducing raw material cost and weight. It's all here – dramatic styling, easy hookup and adjustments, excellent audio quality and QSC reliability.

GX amplifiers deliver just the right amount of power to the most popular speakers used by entertainers. Most loudspeaker manufacturers recommend an amplifier with power output equal to the speaker's "Program (Music) Power" rating or two times (2 x) the "Continuous (RMS) Power" rating.

The GX3 is ideal for speakers in the 300 watt (Program) range, while the GX5 provides full performance for 500 watt (Program) speakers. Both models supply maximum possible power to 4 ohm and 8 ohm loads. Owners of popular 4 ohm loudspeakers (dual-woofer, two-way models and many subwoofers) will find the 700 watt (4 ohm) power of the GX5 an ideal match.

 All specifications refer to pre-production samples and are subject to change without notice.

GX Series
SPECIFICATIONS GX3 GX5
8 ohms / 1 kHz (both channels driven) 300 W 500 W
8 ohms / 1 kHz (single channels driven) 350 W 600 W
4 ohms / 1 kHz (both channels driven) 425 W 700 W
4 ohms / 1 kHz (single channels driven) 500 W 850 W
Distortion (typical)
  20 Hz - 20 kHz, 1 dB below rated power

8 ohms: less than 0.05%
4 ohms: less than 0.1%
Signal to Noise (20 Hz - 20 kHz) 100 dB
Input Sensitivity 1.2 Vrms
Voltage Gain (8 ohms) 32.2 dB 34.4 dB
Output Circuitry Class B 2-tier Class H
Power Requirements (1/8 power, pink noise at 4 ohms, 120V) 6.3A 6A
Frequency Response 20 Hz - 20 kHz, +0, -1 dB
Dynamic Headroom (4 ohms) 2 dB
Input Impedance (ohms) Greater than 20k (balanced)
Maximum Input Level

+24 dB (16 Vrms)
Input Connectors (each channel) 3-pin XLR and 1/4" TRS, balanced, parallel
Phono, unbalanced
Output Connectors (each channel) Speakon®, 1/4", Binding Posts
Amplifier and Load Protection Short circuit, open circuit, thermal, RF protection
Load protected against DC faults
Front Panel Controls and Indicators Gain controls, 21 detents
Red Clip LEDs, proportional, 0.1% THD threshold
Green Signal LEDs, threshold -35 dB
Blue Power LED, AC on
Rear Panel Controls Full Range / Crossover switch
100 Hz, 3rd order LP (sub), 2nd order HP (top)

Dimensions Height: 3.5" (89 mm) 2RU
Width: 19" (483 mm)
Depth: 10.1" (257 mm)
Weight Net: 27 lbs (12.1 kg)
Shipping: 31 lbs (14.1 kg)
Net: 28 lbs (12.6 kg)
Shipping: 32 lbs (14.6 kg)
Agency Approvals UL, CE, RoHS/WEEE Compliant
AC Power Consumption

AC Current and Heating, 120 VAC
  GX3 GX5
Operating Condition AC amps BTU / hr AC amps BTU / hr
Idle 0.2 44 0.3 60
8 + 8 ohms, 1/8 power 1 4.1 904 3.3 734
8 + 8 ohms, 1/3 power 2 6.1 1160 8.5 1456
8 + 8 ohms, full power 3 9.75 1109 16.2 1891
4 + 4 ohms, 1/8 power 1 6.3 1515 5.8 1160
4 + 4 ohms, 1/3 power 2 9.4 2105 11.2 2162
4 + 4 ohms, full power 3 15.0 2297 24.5 3754
1 1/8 power represents typical operating conditions
2 1/3 power represents peak program levels
3 Full power is breaker limited to short periods
For 230 V, multiply AC current by 0.5
For 100 V, multiply AC current by 1.25


* At onset of clipping


All Specifications Subject to Change Without Notice.




  Inputs
XLR, 1/4" TRS and phono input connectors for compatibility with any source.
Crossover
Subwoofer/Satellite crossover built-in.
Outputs to Speakers
Speakon® combo output connector accepts 1/4" or Speakon 2 wire connectors.
Binding post output for compatibility with any loudspeaker wiring scheme

 Professional Power Amplifiers

Loudspeaker Compatibility Chart



Manufacturer Series Model Impedance Program (Music) Power Rating* Recommended Amplifier
JBL JRX JRX112i 8 Ω 500 W GX5
JBL JRX JRX115 8 Ω 500 W GX5
JBL JRX JRX125 4 Ω 1000 W GX5
JBL JRX JRX118S 4 Ω 750 W GX5
JBL SoundFactor SF112i 8 Ω 500 W GX5
JBL SoundFactor SF115 8 Ω 500 W GX5
JBL SoundFactor SF125 4 Ω 1000 W GX5
JBL EON EON1500 8 Ω 450 W GX5
JBL MPro MP212 8 Ω 500 W GX5
JBL MPro MP215 8 Ω 500 W GX5
JBL MPro MP225 4 Ω 1000 W GX5
JBL MPro MP255S 4 Ω 1000 W GX5
JBL MPro MP410 8 Ω 600 W GX5
Yamaha ClubV** S112V 8 Ω 350 W GX3
Yamaha ClubV** S115V 8 Ω 500 W GX5
Yamaha ClubV** S215V 4 Ω 1000 W GX5
Yamaha ClubV** SM10V 8 Ω 250 W GX3
Yamaha ClubV** SM12V 8 Ω 350 W GX3
Yamaha ClubV** SW115V 8 Ω 500 W GX5
Yamaha ClubV** SW118V 8 Ω 600 W GX5
Yamaha ClubV** C112V(A) 8 Ω 350 W GX3
Yamaha ClubV** C115V(A) 8 Ω 500 W GX5
Yamaha ClubV** C215V 4 Ω 1000 W GX5
Yamaha ClubV** CM10V 8 Ω 250 W GX3
Yamaha ClubV** CM12V 8 Ω 350 W GX3
Yamaha ClubV** CW115V 8 Ω 500 W GX5
Yamaha ClubV** CW118V 8 Ω 600 W GX5
Yamaha BR Series BR10 8 Ω 250 W GX3
Yamaha BR Series BR12 8 Ω 300 W GX3
Yamaha BR Series BR15 8 Ω 400 W GX5
Yamaha BR Series BR12M 8 Ω 300 W GX3
Yamaha BR Series BR15M 8 Ω 400 W GX5
Peavey PV® Series PV115 8 Ω 400 W GX5
Peavey PV® Series PV215 4 Ω 700 W GX5
Peavey PV® Series PV112 8 Ω 400 W GX5
Peavey PV® Series PV118 8 Ω 400 W GX5
Peavey PV® Series PV15M 8 Ω 500 W GX5
Peavey PV® Series PV12M 8 Ω 500 W GX5
Peavey PR® Series PR15 8 Ω 400 W GX5
Peavey PR® Series PR12 8 Ω 400 W GX5
Peavey PR® Series PR12N 8 Ω 400 W GX5
Peavey PR® Series PR Sub 8 Ω 400 W GX5
EV Force I Series Force i 8 Ω 500 W GX5
EV Force I Series Force i Monitor 8 Ω 500 W GX5
B-52 LX LX-1515 4 Ω 800 W GX5
B-52 LX LX-218 8 Ω 550 W GX5
Mackie   C200 8 Ω 350 W GX3
Mackie   C300z 8 Ω 500 W GX5
Cerwin Vega   EL36B 8 Ω 500 W GX5
Notes:
All specifications are taken directly from manufacturers' published data.
*If not published, this figure will be calculated as 2 x the continuous (RMS) power rating
** Earlier Club series models will have similar specifications
GX amplifier specified will deliver power within + or - 1 dB of Program Power Spec.
GX5 4 Ω 550 W to 900 W
GX5 8 Ω 400 W to 630 W
GX3 4 Ω 335 W to 540 W
GX3 8 Ω 240 W to 375 W
